IP-9 SC Connector
The IP-9 SC Connector delivers compact, high-performance outdoor connectivity with an IP68-rated design that withstands harsh environments. Its small footprint saves space without compromising durability, making it ideal for FTTH and outdoor telecom networks. Featuring a patented Safe Lock Ring, it ensures secure and reliable connections in demanding conditions.
- Compact IP68-Rated Design for outdoor and harsh environments
- SC-Style Single-Fiber Connector optimized for FTTH networks
- Rugged Construction with 100 lbf pull-force strength
- Patented Safe Lock Ring for added connection security
- Quick and Easy Termination for field deployment
IP-9 SN Connector
The IP-9 SN Connector combines a compact, IP68-rated design with rugged outdoor performance. Featuring SN® 2-fiber connectivity, it offers reliable protection against dust, water, and vibration—ideal for FTTH and FTTA applications. The patented Safe Lock Ring ensures a secure, stable connection in the harshest environments.
- Small Footprint, IP68-Rated for outdoor and harsh environments
- SN® 2-Fiber Design optimized for FTTH and FTTA networks
- Ruggedized Housing with 100 lbf (450 N) pull-force strength
- Patented Safe Lock Ring for enhanced connection security
- Fast, Tool-Free Termination for quick field installation
- Typ. 0.05–0.12 dB | Max ≤ 0.25 dB
- Return Loss: ≥55 dB (SM) | ≥25 dB (MM)
- Operating Temp: –40 °C to +75 °C
- Pull Force: 100 lbf (450 N) | Rating: IP68
IP-9 MPO Connector
The IP-9 MPO Connector delivers high-density, outdoor-rated performance in the industry’s smallest footprint. Engineered with IP68 protection, a 100 lbf pull-force, and a patented Safe Lock Ring, it ensures secure and reliable fiber connections for FTTH, FTTA, and outdoor networks.
- Compact IP68-rated outdoor design
- Supports up to 24-fiber MT ferrules
- 100 lbf (450 N) rugged pull strength
- Secure Safe Lock Ring mechanism
- SpecsInsertion Loss: 0.10–0.25 dB typical
- Return Loss: ≥ 60 dB (SM) / ≥ 25 dB (MM)
- Temperature: –40 °C to +75 °C
- Durability: < 0.3 dB change, 50 matings
IP-16 SN Connector
The IP-16 SN® Connector delivers IP68-rated durability and high-performance fiber connectivity for outdoor and harsh environments. Featuring a compact duplex SN® design, it supports higher fiber density without compromising performance. Its Safe Lock Ring and quick bayonet mechanism ensure secure, reliable connections in any OSP or multi-fiber application.
- IP68-rated ruggedized outdoor connector
- 4/6-fiber SN® design for high-density networks
- Ceramic ferrules for superior optical performance
- Ideal for multi-fiber assemblies and enclosures
IP-16 MPO Connector
The IP-16 MPO Connector delivers IP68-rated protection and high-density performance for outdoor and harsh environments. Its MT-style ferrule supports up to 24 fibers, ensuring fast, secure, and tamperproof connections through a Safe Lock Ring and bayonet locking system — ideal for multi-fiber assemblies and outdoor enclosures.
- IP68-rated ruggedized outdoor connector
- Supports up to 24 fibers with MT ferrule design
- High-performance interconnect for OSP networks
- Ideal for multi-fiber assemblies and enclosures
IP-16 LC Connector
The IP-16 LC Connector delivers IP68-rated protection and rugged reliability for demanding outdoor and OSP environments. Designed with a quick bayonet locking system and Safe Lock Ring, it ensures secure, tamper-proof fiber connections while maintaining superior optical performance.
- IP68-rated ruggedized outdoor connector
- LC 2-fiber design for versatile OSP use
- Quick bayonet lock for easy installation
- Compatible with multiple cable sizes
IP-16 SC XP-FIT Connector
The IP-16 SC XP-FIT Connector combines IP68-rated durability with the convenience of field-installable XP-FIT technology, delivering reliable fiber connections in harsh outdoor environments. Its bayonet locking and Safe Lock Ring ensure secure, tamper-proof performance for FTTH and OSP networks.
- IP68-rated field-installable design
- SC 1-fiber connector for FTTH applications
- Quick, tool-free installation
- Supports multiple cable sizes for flexible deployment
